Product Introduction:
The hat purlin roll forming machine is designed for producing hat-shaped steel profiles widely used in modern roofing systems, wall support structures, and light steel construction frameworks. It provides stable and continuous forming performance with high precision output.
This equipment integrates multiple production steps into a single automated line, including feeding, leveling, forming, punching, and cutting. The system is designed for high efficiency manufacturing environments where consistent quality and fast production speed are required.
The machine adopts an adjustable forming structure, allowing operators to change different profile sizes without replacing the entire roller system. This flexibility helps reduce production cost and improves adaptability for different project requirements.
Its cutting system uses hydraulic control technology to ensure smooth and accurate cutting edges. Combined with high-strength alloy rollers, the machine maintains long service life and stable performance under continuous operation.
The intelligent PLC control system simplifies operation, allowing easy adjustment of production parameters such as length, speed, and batch quantity. Real-time monitoring improves production accuracy and reduces manual intervention.
Technical Specification Table:
| Item | Description |
|---|---|
| Material Type | Galvanized Steel / Cold Rolled Steel |
| Profile Type | Hat Section / Hat Channel |
| Thickness Range | 0.8 – 2.5 mm |
| Production Speed | 8 – 18 m/min |
| Roller Stations | 10 – 16 stations |
| Control System | PLC Automatic Control |
| Cutting Method | Hydraulic Servo Cutting |
| Adjustment Mode | Manual / Automatic Adjustment |
| Shaft Material | High Strength 45# Steel |
| Frame Structure | Welded Heavy Steel Frame |
| Voltage | 380V / 50Hz / 3 Phase |
Production Workflow:
Steel Coil Feeding → Straightening Unit → Roll Forming Section → Punching System (Optional) → Length Measurement → Hydraulic Cutting → Output Table
Core Features:
Application Fields:
The hat-shaped roll forming machine is an indispensable and efficient production equipment in the field of steel structure construction.
It is mainly used to manufacture purlins with a unique hat-shaped cross-section.
This type of purlin is named because its structure resembles a hat and is widely used in the roof and wall support systems of industrial plants, large warehouses and commercial buildings.
The hat-shaped roll forming machine quickly converts metal coils into hat-shaped purlins of standard or customized specifications through an automated rolling process.
Compared with traditional processing methods, the production efficiency is increased several times, and the product dimensional accuracy and surface quality can be guaranteed.
The equipment is equipped with an intelligent control system.
The operator only needs to enter the parameters on the touch screen to automatically adjust the roller spacing, pressure and forming speed, so as to achieve rapid switching production of purlins of different models.
In addition, the hat-shaped roll forming machine also has functions such as fault warning and energy consumption monitoring, which effectively reduce maintenance costs and production risks.
With the advantages of high efficiency, precision and stability, the hat-type roll-forming machine not only significantly shortens the construction period of steel structure buildings, but also enhances the stability and durability of the overall building structure with high-strength and corrosion-resistant purlin products, becoming the core equipment for modern industrialized construction production.
Xinnuo Roll Forming Machine Co., Ltd., established in 1995, is a leading enterprise specializing in the design, development, manufacturing, and sales of various cold roll forming equipment.
Located in Botou Economic Development Zone, the company benefits from a well-developed electromechanical manufacturing industry and a complete industrial chain...[ Read More >>]
